ARC-1200 Stud Welder
- Designed and built in U.S.A.
- Regulated ouput current
- Precise weld time and weld current adjustments
- Dual time range
- Short cycle capabilities
- Diagnostic L.E.D.’s
- State-of-the-art gun control circuitry
- Built-in chuck saver
- Portable
The Pro-Weld International
ARC-1200 is a compact and portable stud welding power supply capable of welding
studs thru 5/8″ diameter weld base. The fully regulated power supply, which operates on
three-phase power, produces a smooth, stable welding arc. Both the weld time and weld
current are infinitely adjustable for preciseness and repeatability.
For maximum flexibility the weld time can be switched between two ranges.
The expanded short time range provides fine adjustment of weld time for special short
cycle applications such as welding to thin materials
A specially designed electronic gun control circuit has been incorporated to
increase overall reliability. If a fault condition occurs due to a shorted
gun solenoid or a faulty control cable, the circuit will prevent gun retriggering
and eliminate damage to printed circuit boards.
Components
| Description | Part No. |
|---|---|
| System | 100-0208 1200 |
| Ground Cable 25 ft. x 1/0 | 125-0102 1200 |
| Combo Cable 50 ft. x 1/0 | 125-1000 1200 |
| Power Supply | 200-0018 1200 |
| Weld Gun | 300-0500 1200 |
Specifications
| Dimensions | 27-1/2″H x 17″W x 22″D |
|---|---|
| Output | 1300 Amps @ 40 VDC |
| Weight | 194 lbs |
| Duty Cycle | 1/4″ 20/Min 5/16″ 15/Min 3/8″ 13/Min 1/2″ 8/Min 5/8″ 4/Min |
| Input | 230/460/575 VAC 3 Phase 60 Hz |
| Fusing | 120/60/50 Delay Type |
| Time Control | Stepless Adjustable Range A: .06 – .3 Sec, Range B: .1 – 1.0 Sec |
| Current Control | Stepless Adjustable 400 – 1300 Amps |
.
